Signature Server®Hot/Cold Food Station
Three 12" x 20" x 6 5/8" deep (30.5 x 50.8 x 16.8 cm) hot well openings and one 24 3/4" x 19 3/8" x 8" deep (62.9 x 49.2 x 20.3 cm) cold pan opening (2 pan).
This symbol represents products that are certified to safely perform its job as intended. This product has earned this certification by undergoing rigorous testing against standards developed by UL.
California’s Proposition 65, officially known as the Safe Drinking Water and Toxic Enforcement Act, is intended to protect the state’s drinking water sources from contaminants that may be harmful. It has recently been amended, and the change that impacts Vollrath requires more specific labeling for some of our products that contain chemicals identified in Proposition 65.
4-Series Hot/Cold Food Station
Three 12" x 20" x 6 5/8" deep (30.5 x 50.8 x 16.8 cm) hot well openings and one 24 3/4" x 19 3/8" x 8" deep (62.9 x 49.2 x 20.3 cm) cold pan opening (2 pan)
Three 12" x 20" x 6 5/8" deep (30.5 x 50.8 x 16.8 cm) hot well openings and one 24 3/4" x 19 3/8" x 8" deep (62.9 x 49.2 x 20.3 cm) cold pan opening (2 pan)
18 gauge work surface
Optional 14 gauge work surface available
Energy efficient 625W elements
Touch-Temp® electronic control
High-density fiberglass insulation surrounds hot wells
Cold Pan: 1 1/2" (3.2 cm) drain standard
Foamed-in-place polyurethane insulation surrounds cold well
R290 refrigerant
Separate drain hoses and valves on operator side of base
NSF Certified, storage not available
Note: 4-Series equipment orders cannot be cancelled or returned.
Product Specifications
Unit Dimensions
| Name | Value |
|---|---|
| Overall Dimensions (IN) | 74 x 28 x 27 |
| (W) Width (IN) | 74 |
| (W2) Secondary Width (IN) | 12 |
| (W3) Additional Width (IN) | 24.75 |
| (D) Depth (IN) | 28 |
| (D2) Secondary Depth (IN) | 19.875 |
| (H) Height (IN) | 27 |
| (H2) Secondary Height (IN) | 5.4375 |
| Caster Size (IN) | 4 |
| (W) Width (CM) | 188 |
| (W2) Secondary Width (CM) | 30.5 |
| (W3) Additional Width (CM) | 62.9 |
| (D) Depth (CM) | 71 |
| (D2) Secondary Depth (CM) | 50.5 |
| (H) Height (CM) | 69 |
| (H2) Secondary Height (CM) | 13.8 |
| Caster Size (CM) | 10 |
Electrical
| Name | Value |
|---|---|
| Amps | 11.6-26.1 |
| Cord Length (IN) | 8 |
| Cord Length (CM) | 2.4 |
| hp | 1/5 |
| Plug | NEMA5-30P,NEMA5-50P,NEMA14-20P |
| Voltage | 120-240 |
| Watts | 625 |
Construction
| Name | Value |
|---|---|
| Compressor Capacity (Btu/hr) per Compressor | 2800, 6400 |
| Component Type | Rectangular Base |
Case Lot Measurement
| Name | Value |
|---|---|
| Case Lot | 1 |
| Case Width | 40 |
| Case Height | 67 |
| Case Length | 78 |
| Case Lot Cube (ft.) | 120.97 |
| Case Lot Weight (lbs.) | 725.0 |
