CF2-3600
208-240-Volt 10 lb. standard-duty countertop fryer
With Vollrath® standard-duty fryers, you can count on safe handling, durability and low maintenance.
This symbol represents products that are certified to safely perform its job as intended. This product has earned this certification by undergoing rigorous testing against standards developed by UL.
208-240-Volt 10 lb. standard-duty countertop fryer
With Vollrath® standard-duty fryers, you can count on safe handling, durability and low maintenance. Our space-saving single fryer combines performance with a minimal footprint, so your guests enjoy crisp fried foods while you appreciate a compact design that’s easy to handle and clean. Standard fryer ships with 2 stainless steel wire baskets, each featuring a cool-touch handle for comfort and safety.
New 208-240-volt fryer heads deliver 20% more power
Standard fryer with single well delivers 1800 watts of power
New components deliver quality, safety and durability
Lighted power switch and oil-ready indicators
Thermostatically controlled to 375°F; auto shutoff at 500°F
3-position fryer head enables easy pan removal and cleaning
One-piece stainless tank with handles lifts out for cleaning
Product Specifications
Model Information
| Name | Value |
|---|---|
| Model | FFA8110 |
| UPC | 671080969374 |
Unit Dimensions
| Name | Value |
|---|---|
| (W) Width (IN) | 10.75 |
| (D) Depth (IN) | 17.125 |
| (H) Height (IN) | 12.625 |
| (DB) Depth of Body (IN) | 16.75 |
| (W) Width (CM) | 27.4 |
| (D) Depth (CM) | 43.5 |
| (H) Height (CM) | 32.1 |
| (DB) Depth of Body (CM) | 42.5 |
Electrical
| Name | Value |
|---|---|
| Amps | 13 - 15 |
| Cord Length (IN) | 48 |
| Cord Length (CM) | 121.9 |
| Plug | NEMA 6-15P |
| Voltage | 208-240 |
| Watts | 2700 - 3600 |
Construction
| Name | Value |
|---|---|
| Construction Material | Stainless Steel |
| Construction Material 2 | Electrical Components |
| Material Type | Metals |
| Number of Wells | 1 |
| Product Function | Fryer |
Case Lot Measurement
| Name | Value |
|---|---|
| Case Lot | 1 |
Product Accessories
Product Parts
| Name | Part # | Price |
|---|---|---|
| 240V HEATING ELEMENT KIT | 351813-02-1 | $70.10 |
| RUBBER GASKET | 351788-09-1 | $1.60 |
| INTERLOCK SWITCH KIT | 351814-1 | $18.50 |
| 240V RELAY KIT | 351815-02-1 | $84.90 |
| FRYER HEAD OVERLAY | 351788-01-1 | $16.50 |
| FRYER INTERLOCK MAGNET | 351792-04-1 | $12.20 |
| FRYER HEAD 208-240V | 351790-1 | $460.80 |
| REGULATING THERMOSTAT | 351788-12-1 | $13.30 |
| HI-LIMIT THERMOSTAT COVER | 351788-03-1 | $10.80 |
| 240V PILOT LIGHT | 351788-18-1 | $31.60 |
| RECTANGULAR POWER SWITCH 240V | 352740-1 | $11.10 |
| Control Knob | 351788-06-1 | $7.60 |
| HI-LIMIT THERMOSTAT | 351788-02-1 | $13.30 |
| 10LB BODY ASSM | 351816-01-1 | $200.40 |
| SPILLAGE PAN ASSM | 351797-1 | $76.40 |
| 6-15 POWER CORD STRT STRN RELF | 354201-1 | $53.60 |
| FRYER BEZEL & OVERLAY | 354203-1 | $53.10 |
| Kit, Foot, 1.00" OD, 20Mm LG | 351775-1 | $10.40 |
