37076
Signature Server® NSF7 Cold Station
NSF Certified..
This symbol represents products that are certified to safely perform its job as intended. This product has earned this certification by undergoing rigorous testing against standards developed by UL.
California’s Proposition 65, officially known as the Safe Drinking Water and Toxic Enforcement Act, is intended to protect the state’s drinking water sources from contaminants that may be harmful. It has recently been amended, and the change that impacts Vollrath requires more specific labeling for some of our products that contain chemicals identified in Proposition 65.
4-Series NSF7 Cold Station
NSF Certified.
Entire base constructed of corrosion resistant 18 gauge stainless steel with standard black laminate.
Optional brushed stainless steel exterior finish or choose from hundreds of laminate finishes
Corner trim in stainless steel
Heavy-duty 4" (10 cm) swivel casters with brakes
5 1/4" (13.3 cm) clearance between floor and bottom of unit
NSF7 listed: Hold food temperatures between 33°F and 41°F (0.6°C and 5°C)
Recessed display well is 3" (7.6 cm) below the work surface
Refrigeration coils surround sides of recess and display wells
Optional 14 gauge work surface available
Foamed-in-place polyurethane insulation
Display depth: 6 5/8" (16.8 cm)
1 1/2" (3.2 cm) drain standard
8 foot power cord standard
R134A refrigerant
Storage not available
Product Specifications
Unit Dimensions
| Name | Value |
|---|---|
| (W) Width (IN) | 74 |
| (W2) Secondary Width (IN) | 63.125 |
| (H) Height (IN) | 34 |
| (H2) Secondary Height (IN) | 5.4375 |
| Caster Size (IN) | 4 |
| (W) Width (CM) | 188 |
| (W2) Secondary Width (CM) | 16.3 |
| (H) Height (CM) | 86.4 |
| (H2) Secondary Height (CM) | 13.8 |
| Caster Size (CM) | 10 |
Electrical
| Name | Value |
|---|---|
| Amps | 7.8-8.8 |
| Cord Length (IN) | 8 |
| Cord Length (CM) | 2.4 |
| hp | 1/3 |
| Plug | NEMA 5-15P |
| Voltage | 120 |
Construction
| Name | Value |
|---|---|
| Compressor Capacity (Btu/hr) per Compressor | 4800 |
| Component Type | Rectangular Base |
Case Lot Measurement
| Name | Value |
|---|---|
| Case Lot | 1 |
| Case Width | 40.5 |
| Case Height | 67.25 |
| Case Length | 77.25 |
| Case Lot Cube (ft.) | 121.76 |
| Case Lot Weight (lbs.) | 488.0 |
Product Downloads
CAD / REVIT
For the most updated list for Vollrath products and CAD drawings
