Affordable Portable Hot Food Station with Buffet Breath Guard
Each well supplied with 525-watt element with infinite setting controls..
This symbol represents products that are certified to safely perform its job as intended. This product has earned this certification by undergoing rigorous testing against standards developed by UL.
60-inch 2-Series Affordable Portable™ Hot Food Station with storage base and door in walnut woodgrain
Each well supplied with 525-watt element with infinite setting controls.
Optional 300 series stainless steel removable plate rest offers a 7" (17.8 cm) wide, stable area
Seamless one-piece 20 gauge 300 series stainless steel work surface
Scratch resistant vinyl clad carbon steel in seven colors
Optional storage with doors - 23" (58.4 cm) deep available
Easy access, fully enclosed clear acrylic breath guard - 12" (30.5cm) clearance
Optional factory installed UL listed 120 volt incandescent lighting assembly showcases food in a dramatic light. Bulbs not included
Each well supplied with 525-watt element with infinite Set
High density glass fiber insulation
Spillage pans required - sold separately
Infinite control switches
Unit depth: 24" (61 cm)
Buffet style acrylic breath guard standard
208-240V now available - see spec sheet
NOTE: Item made to order, cannot be cancelled or returned.
Product Specifications
Model Information
| Name | Value |
|---|---|
| UPC | 029419051670 |
Unit Dimensions
| Name | Value |
|---|---|
| Overall Dimensions (IN) | 30 x 39.5 x 59 |
| (W) Width (IN) | 30 |
| (D) Depth (IN) | 39.5 |
| (H) Height (IN) | 59 |
| (W) Width (CM) | 152.4 |
| (D) Depth (CM) | 100.3 |
| (H) Height (CM) | 149.9 |
| Size | 60-Inch |
Electrical
| Name | Value |
|---|---|
| Amps | 17.5 |
| Hz | 60 |
| Plug | 5-30P |
| Voltage | 120 |
| Watts per Well | 525 |
Construction
| Name | Value |
|---|---|
| Color | Walnut Woodgrain |
| Construction Material | 20-gauge Carbon Steel |
| Control Type | Inifinite Controls |
| Material Type | Metals |
| Number of Wells | 4 |
| Product Function | Hot Food Station |
| Serving System - Base Style | Storage with Door |
| Breath Guard - Type | Buffet |
Case Lot Measurement
| Name | Value |
|---|---|
| Case Lot | 1 |
| Case Width | 40 |
| Case Height | 67 |
| Case Length | 63 |
| Case Lot Cube (ft.) | 97.71 |
| Case Lot Weight (lbs.) | 393.0 |
Product Parts
| Name | Part # | Price |
|---|---|---|
| NUT - ACORN 10-24 X 3/8 NICKEL | 22831-3 | $2.20 |
| SNAP BUSHING HEYCO SB-500-6 | 21528-3 | $0.70 |
| POWER CORD 125V NEMA 5-50P | 26618-1 | $216.10 |
| CASTER W/BRAKE SIGNATURE | 21447-1 | $38.70 |
| PILOT LIGHT - RED 125V | 23065-3 | $15.10 |
| STRAIN RELIEF - FOR 3/8 CORD | 26543-3 | $2.30 |
| PLEXI-60" AFFORDABLE PORTABLE | 26743-1 | $887.80 |
| SWITCH-120/277V 15A SINGLE POL | 24787-1 | $34.90 |
| LAMPHOLDER MEDIUM BASE E26 | 21370-3 | $22.40 |
| 120V-INFINITE CONTROL SWITCH | 24788-1 | $40.80 |
| PLEXI-END AFFORDABLE PORT. | 26718-1 | $86.70 |
| SCREW #6-32 SLOT RND HD ZINC | 26572-3 | $0.70 |
| INFINITE CONTROL KNOB | 26638-3 | $16.30 |
| CASTER W/O BRAKE SIGNATURE | 21448-1 | $38.10 |
| NUT W/WASHER #10-24 ZINC PLT | 21574-3 | $0.70 |
| HEATING ELEMENT-120V 525 WATT | 26509-1 | $89.50 |
Product Downloads
CAD / REVIT
Customer Questions
Be the first to ask a question
