30" Cayenne® Cord and Plug Heat Strip

72678019

30" Cayenne® Cord and Plug Heat Strip

  • Made in USA
  • National Sanitation Foundation
  • Underwriter Laboratories

    This symbol represents products that are certified to safely perform its job as intended. This product has earned this certification by undergoing rigorous testing against standards developed by UL.

$270.24 MSRP Manufacturer Suggested Retail Price (MSRP) is a predetermined percentage off of list price (shown is US Dollars) and is valid for vollrathfoodservice.com and the United States and Canada only. Dealer pricing may differ. These prices do not include potential shipping costs. Any sales tax applicable will be added to the final price upon quote or purchase.
$450.40 List Price List price (shown is US Dollars) is valid for vollrathfoodservice.com and the United States and Canada only. Dealer pricing may differ. These prices do not include potential shipping costs. Any sales tax applicable will be added to the final price upon quote or purchase.

Unique heating design offers greater and more even heat dispersion for more effective warming

  • Sheathed style element for dependability and longer life
  • Structurally engineered aluminum heater housing offers maximum strength with minimal weight
  • Bright anodized aluminum heat reflector generates more even heat over food holding area
  • Reflector assembly is field-adjustable allowing operator to direct heat pattern where needed
  • Cord and Plug units must be mounted on legs
  • One year parts and labor warranty supported by a service network for worry-free operation. Additional one year warranty on heating element (parts only).
  • Mounting and trim options available
  • NOTE: Cayenne Heat Strips and Cayenne Light Strips are custom ordered and cannot be cancelled or returned

Product Specifications

Engineering front view
Engineering top view
Model Information
Name Value
UPC 029419523900
Unit Dimensions
Name Value
Overall Dimensions (IN) 30 x 9 x 2.875
(W) Width (IN) 30
(D) Depth (IN) 9
(D2) Secondary Depth (IN) 6
(D3) Additional Depth (IN) 3
(H) Height (IN) 2.87
(W) Width (CM) 76.2
(D) Depth (CM) 22.9
(D2) Secondary Depth (CM) 15.2
(D3) Additional Depth (CM) 7.62
(H) Height (CM) 7.3
Size 30
Electrical
Name Value
Amps 5.8
Cord Length (IN) 72
Cord Length (CM) 182.8
Plug NEMA 5-15P
Voltage 120
Watts 690
Construction
Name Value
Construction Material Aluminum
Material Type Metals
Case Lot Measurement
Name Value
Case Lot 1
Case Width 12
Case Height 5.75
Case Length 36
Case Lot Cube (ft.) 1.4
Case Lot Weight (lbs.) 8.8
Product Accessories
Name Item #
Cayenne® Heat Strips Accessories 4450613
Product Parts
Name Part # Price
TOGGLE SWITCH 3/4HP 120-240VAC 17925-1 $42.53
NUT KEPS #6-32 17019-3 $0.80
HEATING ELEMENT SIZE 30 BLUE 1791516-1 $43.03
HEYCO STRAIN RELIEF 17045-3 $2.40
16 GA. POWER CORD 120V 17085-1 $21.30
TOGGLE CAP-BLACK 17939-1 $1.58

Warranty Information

Terms of Sale

Product Downloads

Resource preview Heat Strip, Cayenne®, Cord and Plug - Specification Sheet (English)
Resource preview Heat and Light Strips, Cayenne® - Operator's Manual (Multi-Language)

CAD / REVIT

For the most updated list for Vollrath products and CAD drawings

Visit VOLLRATH.KCLCAD.COM
